Gate Valve Iran

flat gate valve kit

Truck mounted concrete pump spare parts include concrete delivery components, hydraulic assemblies, articulated boom systems, and heavy duty wear resistant elements. Nominal operating pressure typically ranges from 85 to 130 bar, with pumping capacities between 50 and 180 cubic meters per hour. Delivery cylinders are designed with internal diameters from 180 to 230 millimeters and strokes of 1400 to 2100 millimeters. Concrete pistons use polyurethane packings with high abrasion resistance and pressure tolerance up to 120 bar. Pipes and elbows are manufactured from alloy steel with hardness between 58 and 65 HRC. Wear plates and cutting rings exceed 600 Brinell hardness for extended durability in harsh aggregate conditions.

The articulated boom structure is fabricated from high strength steel with yield strength above 700 megapascals to ensure stability at height. Boom length varies from 30 to 65 meters and includes 4 to 6 articulated sections. A hydraulic piston pump rated at 120 to 220 kilowatts delivers 220 to 330 liters per minute. The S valve or rock valve switches concrete flow at 20 to 35 cycles per minute. Machining tolerances for pins and bushings are maintained below 0.05 millimeters. Quality control includes hydrostatic pressure testing, leakage evaluation, and non d

Kitz 3-inch Class 300 flanged gate valve

The Kitz 3-inch Class 300 flanged gate valve is manufactured with a steel or ductile iron body, rated for Class 300 pressure per ASME B16.34 standards. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for corrosion and wear resistance, capable of handling operating temperatures from 0°C to 425°C. The flanged design conforms to ASME B16.5, ANSI B16.47, or JIS B2220 standards, allowing secure and fast installation between standard flanged pipelines. Internal sealing with high-performance washers ensures minimal leakage and quiet, reliable operation.

Depending on body material, the valve weighs between 15 and 25 kilograms. The body and disc are designed to withstand pressure surges and impacts, making it suitable for water, steam, oil, and other industrial and chemical fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for easy installation and long-term protection. The Kitz 3-inch Class 300 flanged gate valve offers robust construction, long service life, and safe operation, making it a primary choice for oil, gas, power plants, and high-pressure industrial pipelines.

Kitz 4-inch Class 300 flanged gate valve

The Kitz 4-inch Class 300 flanged gate valve is manufactured with a steel or ductile iron body, rated for Class 300 pressure per ASME B16.34 standards. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for corrosion and wear resistance, capable of handling operating temperatures from 0°C to 425°C. The flanged design conforms to ASME B16.5, ANSI B16.47, or JIS B2220 standards, allowing secure and rapid installation between standard flanged pipelines. Internal sealing with high-performance washers ensures minimal leakage and quiet, reliable operation.

Depending on body material, the valve weighs between 18 and 28 kilograms. The body and disc are designed to withstand pressure surges and impacts, making it suitable for water, steam, oil, and other industrial and chemical fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for easy installation and long-term protection. The Kitz 4-inch Class 300 flanged gate valve offers robust construction, long service life, and safe operation, making it an ideal choice for oil, gas, power plants, and high-pressure industrial pipelines.

Kitz 2-inch Class 300 gate valve

The Kitz 2-inch Class 300 gate valve is manufactured with a steel or ductile iron body, rated for Class 300 pressure according to ASME B16.34 standards. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for corrosion and wear resistance, capable of handling operating temperatures from 0°C to 425°C. The flanged design conforms to ASME B16.5, ANSI B16.47, or JIS B2220 standards, allowing secure and fast installation between standard flanged pipelines. Internal sealing with high-performance washers ensures minimal leakage and quiet, reliable operation.

Depending on body material, the valve weighs between 8 and 12 kilograms. The body and disc are designed to withstand pressure surges and impacts, making it suitable for water, steam, oil, and other industrial and chemical fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for long-term protection and easy installation. The Kitz 2-inch Class 300 gate valve offers robust construction, long service life, and safe operation, making it a reliable choice for oil, gas, power plants, and high-pressure industrial pipelines.

Kitz 4-inch Class 300 flanged gate valve

The Kitz 4-inch Class 300 flanged gate valve is manufactured with a steel or ductile iron body, rated for Class 300 pressure per ASME B16.34 standards. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for corrosion and wear resistance, capable of handling operating temperatures from 0°C to 425°C. The flanged design conforms to ASME B16.5, ANSI B16.47, or JIS B2220 standards, enabling secure and fast installation between standard flanged pipelines. Internal sealing with high-performance washers ensures minimal leakage and quiet, reliable operation.

Depending on body material, the valve weighs between 20 and 30 kilograms. The body and disc are designed to withstand pressure surges and impacts, suitable for water, steam, oil, and other industrial and chemical fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for easy installation and long-term protection. The Kitz 4-inch Class 300 flanged gate valve offers robust construction, long service life, and safe operation, making it a primary choice for oil, gas, power plants, and high-pressure industrial pipelines.

Kitz 3-inch Class 300 flanged gate valve

The Kitz Class 300 flanged gate valve is manufactured with a steel or ductile iron body and rated for Class 300 pressure according to ASME B16.34. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control, not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for high corrosion and wear resistance, capable of handling operating temperatures between 0°C and 425°C. The flanged design conforms to ASME B16.5 standards, enabling secure and rapid installation between standard flanged pipelines. Internal sealing with high-performance washers ensures minimal leakage and quiet, reliable operation.

Depending on nominal size DN50–DN600, the valve weight ranges from 25 to 450 kilograms. The body and disc are designed to withstand pressure surges and impacts, making it suitable for water, steam, oil, and other industrial and chemical fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for long-term protection and ease of installation. The Kitz Class 300 flanged gate valve offers robust construction, long service life, and safe operation, making it a primary choice for oil, gas, power plants, and high-pressure industrial pipelines.

Kitz 2-inch Class 150 flanged gate valve

The Kitz 2-inch Class 150 flanged gate valve is manufactured with a steel or ductile iron body, rated for Class 150 pressure according to ASME B16.34 standards. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for corrosion and wear resistance, with an operating temperature range of 0°C to 300°C. The flanged connection conforms to ASME B16.5, EN1092-2, or JIS B2220 standards, allowing secure and fast installation between standard flanged pipelines. Internal sealing with high-performance washers minimizes leakage and ensures quiet, reliable operation.

Depending on body material, the valve weighs between 7 and 12 kilograms. The body and disc withstand pressure surges and impacts, making it suitable for water, steam, oil, and industrial fluids. Flanges with standard bolt patterns and corrosion-resistant coating ensure quick installation and long-term protection. The Kitz 2-inch Class 150 flanged gate valve provides long service life, easy maintenance, and reliable operation, making it an ideal choice for water, wastewater, power plants, and medium-pressure industrial pipelines.

Kitz Class 300 6-inch flanged gate valve

The Kitz Class 300 flanged gate valve is manufactured with a steel or ductile iron body, rated for Class 300 pressure per ASME B16.34 standards. It operates as a gate valve with a sliding disc mechanism, providing full open or closed flow control, not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze for high corrosion and wear resistance, capable of handling operating temperatures between 0°C and 425°C. The flanged design conforms to ASME B16.5 standards, allowing secure and rapid installation between standard flanged pipelines. Internal sealing with high-performance washers ensures minimal leakage and reliable, quiet operation.

Depending on nominal size DN50–DN600, the valve weight ranges from 25 to 450 kilograms. The body and disc are designed to withstand pressure surges and impacts, suitable for water, steam, oil, and other industrial and chemical fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for long-lasting protection and easy installation. The Kitz Class 300 flanged gate valve offers robust construction, long service life, and safe operation, making it a key choice for oil, gas, power plants, and high-pressure industrial pipelines.

Kitz 6-inch flanged gate valve

The Kitz flanged gate valve is manufactured with a steel or ductile iron body, rated for nominal pressures of PN16 to PN40. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze to resist corrosion and wear, with a working temperature range of 0°C to 300°C. The flanged design conforms to EN1092-2, ANSI B16.5, or JIS B2220 standards, allowing seamless installation between standard pipeline flanges. Internal sealing with high-performance washers minimizes leakage, ensuring silent and reliable operation.

Depending on nominal size DN50–DN600, the valve weight ranges from 15 to 350 kilograms. The body and disc design provides resistance to pressure surges and impacts, making it suitable for water, steam, compressed air, oil, and chemical pipelines. Flanges feature standard bolt patterns and epoxy or corrosion-resistant coating for easy installation and protection. The Kitz flanged gate valve offers robust construction, safe operation, and long service life, making it a key choice for water, wastewater, power plants, and high-pressure industrial pipelines.

flat gate valve

Truck mounted concrete pump spare parts include delivery cylinders, hydraulic systems, articulated boom assemblies, and high pressure wear components. Nominal operating pressure typically ranges from 90 to 130 bar, with pumping capacity between 60 and 180 cubic meters per hour. Delivery cylinders are manufactured with internal diameters from 180 to 230 millimeters and strokes of 1500 to 2100 millimeters. Concrete pistons use reinforced polyurethane packings capable of operating up to 120 bar. Pipes and elbows are produced from alloy steel with hardness between 58 and 65 HRC. Wear plates and cutting rings exceed 600 Brinell hardness to extend service life.

The boom structure is fabricated from high strength steel with yield strength above 700 megapascals to minimize deflection and vibration. Boom length varies from 28 to 65 meters and includes 3 to 6 articulated sections. A hydraulic piston pump rated at 110 to 210 kilowatts delivers 200 to 320 liters per minute. The S valve or rock valve switches concrete flow at 20 to 35 cycles per minute. Machining tolerances for pins and bushings are maintained below 0.05 millimeters. Quality control includes hydrostatic pressure testing, boom fatigue evaluation, and non destructive weld inspection.

Kitz 6-inch steel flanged gate valve

The Kitz 6-inch steel flanged gate valve is manufactured with a steel body and rated for PN16 to PN40 pressure. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. Internal components, including the disc and seat, are made of stainless steel or bronze to resist corrosion and wear, with an operating temperature range from 0°C to 300°C. The flanged connection conforms to EN1092-2 or ASME B16.5 standards, allowing secure and rapid installation between standard flanged pipelines. Internal sealing with high-performance washers minimizes leakage and ensures quiet, reliable operation.

Depending on size and pressure rating, the 6-inch Kitz steel gate valve weighs between 35 and 50 kilograms. The body and disc are designed to withstand pressure surges and impacts, making it suitable for water, steam, oil, and other industrial fluids. Flanges feature standard bolt patterns and corrosion-resistant coating for easy installation and long-term protection. The Kitz 6-inch steel flanged gate valve offers robust construction, long service life, and safe operation, making it ideal for industrial pipelines and medium- to high-pressure installations.

Farab rising stem metal seated gate valve model GVMO16

The Farab rising stem metal seated gate valve model GVMO16 is a precision-engineered industrial valve designed for flow shutoff and control in water, steam, and process systems. Its body is made of ductile iron GGG40 with a nominal pressure rating of PN16, and the gate is stainless steel with precision-machined sealing surfaces. The rising stem mechanism allows direct vertical movement of the gate, providing clear visual indication of open or closed position. Stainless steel seat rings and graphite packing ensure reliable sealing at elevated temperatures. Flanged ends comply with EN 1092-2, and dimensions follow DIN 3202 standards. The valve operates up to 200°C and 16 bar pressure.

The Farab GVMO16 gate valve is ideal for pump stations, main transmission lines, and control networks due to its rising stem design. The stainless steel stem is finely threaded to ensure smooth and precise gate movement. A bolted bonnet provides easy access for inspection and maintenance. Machined metal seats guarantee bidirectional, leak-free operation. Each valve is hydrostatically and leakage tested in compliance with API 598 standards to ensure safety, durability, and accurate performance under demanding industrial conditions.

Kitz 2-inch Class 300 stainless steel gate valve

The Kitz 2-inch Class 300 stainless steel gate valve is manufactured with a 304 or 316 stainless steel body and disc, rated for Class 300 pressure per ASME B16.34 standards. It operates as a gate valve with a linear sliding disc mechanism, providing full open or closed flow control and is not suitable for throttling. The internal seat is made of stainless steel or bronze for high corrosion and wear resistance, capable of handling operating temperatures from 0°C to 425°C. The flanged design conforms to ASME B16.5 standards, enabling secure and fast installation between standard flanged pipelines. Internal sealing with high-performance washers minimizes leakage.

Depending on size and body material, the valve weighs between 5 and 8 kilograms. Its robust design withstands pressure surges and impacts, making it suitable for water, steam, oil, and industrial or chemical fluids. Flanges with standard bolt patterns and corrosion-resistant coating ensure easy installation and long-term protection. The Kitz 2-inch Class 300 stainless steel gate valve offers long service life, safe operation, and easy maintenance, making it a reliable choice for oil, gas, power plants, and high-pressure industrial pipelines.

Farab metal seated O-ring gate valve model GVO16

The Farab metal seated O-ring gate valve model GVO16 is an industrial-grade valve engineered for on-off flow control in water, steam, and process pipelines. The body is made of ductile iron GGG40 with a nominal pressure rating of PN16, and the stainless steel gate is precision-machined to provide tight sealing. O-rings made of NBR or EPDM are used for bonnet and stem sealing, offering excellent resistance to temperature, pressure, and abrasion. Flanged ends conform to EN 1092-2, and installation dimensions follow DIN 3202. The valve operates within 0–200°C temperature and up to 16 bar pressure.

The Farab GVO16 gate valve features a straight-through flow path to minimize pressure drop and enhance hydraulic efficiency. The stainless steel stem ensures durability, and the bolted bonnet allows easy maintenance and inspection. Multiple O-ring sealing layers are employed in critical zones to prevent leakage under variable pressure conditions. Precision-machined metal seats provide bidirectional leak-tight performance. Each valve is hydrostatically and leakage tested in accordance with API 598 standards to ensure safety, longevity, and consistent performance under demanding operating conditions.

Farab metal seated gate valve with stainless rings model GVS25

The Farab metal seated gate valve with stainless rings model GVS25 is a heavy-duty industrial valve designed for high-pressure applications in oil, gas, and steam systems. The body is made of carbon steel ASTM A216 WCB with a nominal pressure rating of PN25. The gate is stainless steel with precision-machined sealing surfaces, and the seat rings are made of 304 stainless steel for superior corrosion and wear resistance. Flanged connections conform to EN 1092-2, and installation dimensions follow DIN 3202. The valve operates up to 400°C and 25 bar pressure, making it suitable for high-pressure steam and process pipelines.

The Farab GVS25 gate valve features a straight-through bore to minimize pressure drop and optimize flow efficiency. The stainless steel stem and heat-resistant graphite packing ensure reliable sealing under thermal stress. The bolted bonnet design allows easy access for maintenance and inspection. Precision-machined stainless steel seats provide bidirectional, leak-free operation. Each valve is hydrostatically and leakage tested according to API 598 standards to ensure safety, durability, and consistent performance under demanding conditions.
