Rotating 2006 Antenna

The Model 2006 motorized antenna utilizes a 24V DC stepper motor with 3.5 Nm torque and speed control from 0 to 15 degrees per second. This system provides full support for UHF 470-860 MHz and VHF 174-230 MHz bands. Antenna gain reaches 14 dBi at the UHF mid-band and 10 dBi in the VHF band. Input impedance is 75 ohms using low-loss RG-11 coaxial cable. Continuous 360-degree rotation with 0.5-degree positioning accuracy is provided by an internal optical encoder. The antenna structure is made of 6061-T6 aluminum alloy with anti-corrosion polyurethane coating. Structural wind resistance is certified for speeds up to 120 km/h. The main reflector arm measures 120 cm in length with a 4 cm cross-section diameter. The controller supports command input via RS-485 protocol or an infrared interface.

The mechanical structure incorporates a 50 mm stainless steel spherical bearing supporting an axial load of 100 kg. A direct grounding system with less than 3 ohms resistance is implemented for lightning protection. A Low-Noise Amplifier with 1.2 dB noise figure and 20 dB gain is housed in the base compartment. The output connector is an N-Type Female with a silicone sealing washer. Power for the motor and amplifier is supplied by a 24V 5A adapter. This antenna can program and store up to 10

Rotating 2010 Antenna

The Model 2010 motorized antenna features a 1.8-meter diameter aluminum dish with a 1.2 mm thickness. Its surface reflection efficiency is at least 85% at 12 GHz frequency. A synchronous AC drive motor with 120 Nm output torque handles positioning. The system provides 360-degree azimuth rotation at a speed of 1.5 degrees per second. Motor positioning accuracy is ±0.1 degrees using a 16-bit optical encoder. The elevation range is adjustable from 5 to 90 degrees. The base structure is made from 3 mm thick hot-dip galvanized steel. The control system supports DiSEqC 2.0 protocol and has a built-in GPS positioner. It withstands operational winds up to 80 km/h and survival winds up to 150 km/h. The operating temperature range is -30 to +60 degrees Celsius.

The mechanical structure employs a four-arm polar mount with spherical bearing connections. A worm gear with a 1:180 reduction ratio ensures smooth and quiet movement. Mechanical limit sensors prevent movement beyond safe boundaries. Internal wiring uses RG-6 Quad Shield cable with 14 dB loss per 100ft at 1 GHz. The central controller has a 32-bit processor and memory for 200 satellite positions. The user interface includes a color LCD display and an infrared remote control. An external power supply accepts 110-240V AC input and

Desktop 103 Antenna

The Model 103 antenna is designed for UHF/VHF reception within the 470-862 MHz frequency band. Its internal amplifier provides 28 dB gain with less than 2 dB noise figure. The housing is made from durable polycarbonate with an internal conductive coating. The antennas full extended length is 60 cm, retracting to 25 cm. It features 10 active elements with a dipole loop design for bipolar reception. Standard output impedance is 75 ohms via an F-type connector. The amplifier requires 5V DC power at 150 mA current consumption. It can receive DVB-T2/T digital signals with -96 dBm sensitivity. Built-in LTE filtering for the 790-862 MHz cellular interference band is included. Operating temperature ranges from -20 to +60 degrees Celsius. The antenna weighs only 180 grams without its base.

The structure includes a 360-degree swivel base with position-locking capability. Reception elements are constructed from gold-plated anodized aluminum. The circuit board uses SMT Surface Mount Technology for reduced noise. The included cable is a 1.8-meter RG-6 coaxial with copper shielding. A USB port draws power from a TVs USB port or an external adapter. The anti-interference circuit suppresses unwanted signals by up to 30 dB. Antenna gain is manually adjustable across three levels: Low, Medium,

Fix 2011 Antenna

The fixed Model 2011 antenna is designed for full UHF band reception from 470-862 MHz. Its gain is optimized between 14 to 16 dBi. Standard input impedance is 75 ohms with an F-Type female connector. Voltage Standing Wave Ratio VSWR is maintained below 1.8 across the operational band. The main body is constructed from 6063 alloy aluminum with anti-corrosion powder epoxy coating. Overall antenna length is 180 cm with a reflector width of 120 cm. Active elements are made from 6 mm diameter silver-plated copper rods. This antenna can receive DVB-T digital signals with a minimum signal level of -100 dBm. Mechanical resilience is verified for wind speeds up to 130 km/h. The operational temperature range is -30 to +70 degrees Celsius.

The antenna structure is a Yagi-Uda type with 20 elements, including a reflector, driven dipole, and directors. Impedance matching is achieved with an integrated 1:1 balun transformer. Reflectors and directors are made from solid aluminum tubes with a 10 mm diameter. The two-axis mounting bracket is constructed from 2.5 mm thick cold-galvanized steel. This bracket allows elevation adjustment from 0 to 90 degrees and 360-degree azimuth rotation. The antenna optionally includes a built-in LNA with a 1.8 dB noise figure and 20 dB gain. Final antenna weigh

Fix 90 Antenna

The fixed Model 90 antenna is optimized for the UHF 470 to 862 MHz frequency band. Its nominal gain is 8 to 12 dBi with a circular omnidirectional radiation pattern. Standard input impedance is 50 ohms with an N-Female connection port. Voltage Standing Wave Ratio VSWR is guaranteed below 1.5 across the entire operating band. The main structure consists of a fiberglass rod reinforced with a UV-resistant polyurethane coating. Total antenna height is 120 cm with a reflector diameter of 45 cm. Resonant elements are made from 6061 alloy aluminum with an epoxy coating. This antenna can receive DVB-T/T2 digital signals with a minimum signal level of -95 dBm. It withstands wind speeds up to 150 km/h. The operational temperature range is -40 to +85 degrees Celsius.

The antenna structure comprises an 8-element vertical collinear array design. Central feed is accomplished with an integrated 1:1 balun to reduce common-mode noise. A circular aluminum ground plane with a 60 cm diameter focuses the waves. The mounting base is made of 3 mm thick hot-dip galvanized steel for strength. Connectors are waterproof with an IP67 rating for outdoor environments. The antenna operates without an active Low-Noise Amplifier LNA. This design eliminates power consumption and increases reliability. Installe

Desktop 2014 Antenna

The Model 2014 tabletop antenna fully supports UHF 470-862 MHz and VHF 174-230 MHz frequency bands. Its gain is optimized between 12 and 18 decibels. The standard input impedance is 75 ohms using RG6 coaxial cable. Voltage Standing Wave Ratio VSWR remains below 1.5 across the entire operating band. A dual radiation pattern with 60-degree horizontal and 45-degree vertical beamwidth provides optimal coverage. The main body is constructed from UL94-V0 flame-retardant ABS with anodized aluminum arms. Mechanical stability is guaranteed in winds up to 80 km/h. Adjustable arm lengths range from 30 to 120 cm for precise resonance tuning. This antenna can receive DVB-T2 digital signals with a minimum signal level of -85 dBm.

The antenna structure features a dual bow-tie array with a passive reflector. Brass connectors with gold plating minimize oxidation. A built-in 1:4 balun impedance matching transformer is integrated at the antenna base. The integrated Low-Noise Amplifier LNA has a 1.5 dB Noise Figure and adjustable gain of 15-25 dB. The amplifier power is supplied via a 5V USB port or a 12V adapter. Internal SAW filters attenuate mobile interference 800-2200 MHz by up to 40 dB. It can be mounted on a standard 20mm stand or wall with an omnidirectional bracket. Overall dimensions in

Desktop 107 Antenna

The Model 107 desktop antenna features a multi-band design with full UHF 470-862 MHz and VHF 174-230 MHz support. Antenna gain reaches 12 dBi in the UHF band and 8 dBi in the VHF band. Standard input impedance is 75 ohms using RG6 coaxial cable. The front-to-back ratio exceeds 15 dB to reduce background noise. It supports linear horizontal and vertical polarization with 360-degree manual rotation capability. The housing is made of UV-treated polycarbonate to prevent sun damage. Overall dimensions are 45 x 35 x 15 cm with a weight under 800 grams. This antenna can receive DVB-T2/T digital and analog signals. The optimal terrestrial reception range is up to 70 km from the broadcast source.

The internal structure incorporates an active Low-Noise Amplifier with under 2 dB noise figure. The amplifier is powered by a 5V DC adapter or USB port. The radiation pattern is directional circular with a 65-degree beamwidth. Radiating elements are made of 2mm anodized aluminum with anti-corrosion coating. The output connector is an F-Type Female with gold plating to prevent oxidation. The internal LNA filter can attenuate interference below 100 MHz by up to 30 dB. The antenna includes an LED indicator for signal strength reception status. It also supports mounting on a standard VESA 75x75 mm
