Polishing machines

A polishing milling machine is a surface finishing machine tool designed to remove roughness and achieve fine surface quality on metal components. Main motor power typically ranges from 2.2 to 11 kilowatts with spindle speeds between 500 and 6000 rpm. Polishing wheel diameter is selected between 150 and 400 millimeters. Material removal per pass is limited to less than 0.05 millimeter to control thermal stress. Achievable surface finish can reach 0.2 micrometers Ra. Speed control is managed by an inverter to ensure stable torque output.

The machine structure consists of a cast iron or welded steel frame with hardness above 170 Brinell and an adjustable worktable. The spindle shaft is assembled with angular contact bearings and radial runout below 0.005 millimeter. A coolant or polishing compound delivery system provides flow rates between 10 and 30 liters per minute. Applied contact force on the workpiece is adjustable from 50 to 500 newtons. Table load capacity typically ranges from 100 to 500 kilograms. Quality control includes surface roughness measurement, vibration testing below 2.8 millimeters per second, and spindle alignment verification.

Polish and Brush

This dual-purpose machine features a rotating drum with a 7.5 kW inverter-driven AC motor. Drum rotation speed is digitally adjustable from 500 to 3000 RPM. The working drum dimensions are 1500 mm in length and 300 mm in diameter. A quick-change belt system enables switching from polishing to brushing in 90 seconds. It uses 0.5-micron cerium oxide particles for polishing and tungsten carbide wire brushes for brushing. A PID controller keeps the workpiece surface temperature below 50°C. This precision prevents structural alterations in the metal.

The machine structure consists of a welded steel frame with electrostatic powder coating. The particle collection system includes a cyclone and a HEPA filter with 99.97% efficiency. The drum contact force on the workpiece is pneumatically adjustable from 5 to 50 Newtons. The machine achieves surface finishes with roughness Ra from 0.05 microns polish to 0.8 microns brush. Cooling water consumption in a closed cycle is only 20 liters per hour. A transparent safety hood with an auto-cutoff sensor when opened is installed. This feature complies with the CE-EN 12415 safety standard.

Vibratory Lapping and Polishing Machine

Lapping abrasives are made from aluminum oxide or silicon carbide particles. These particles in 16 to 80 grit are bonded onto rigid fiberglass plates. The standard abrasive plate diameter is between 100 and 300 millimeters. Stone thickness varies from 10 to 25 millimeters. Epoxy adhesive resistant to water and chemicals is used for bonding. System motors are designed with high torque and 0.5 to 1.5 kW power. Motor speed is adjustable from 1400 to 2800 RPM. These machines control a removal depth of 0.1 to 3 millimeters.

The machine structure features a vibratory mechanism with 2 to 5 mm amplitude. The suspension system uses waterproof bearings with IP65 rating. The slurry tank for water and particles is made from 304 stainless steel. This tanks capacity ranges from 20 to 100 liters depending on the model. The slurry pump operates at a flow rate of 10 to 50 liters per minute. Continuous filtration removes particles larger than 50 microns. This system achieves surface finishes up to Ra 0.8 micrometers. Advanced machines feature PLC controllers for pressure and time adjustment.

Concrete Grinding and Polishing Machine

The concrete grinder utilizes a three-phase induction motor with 3 to 15 kW power. The disc rotation speed is adjustable from 150 to 650 RPM. It generates an operational surface pressure of 70 to 150 kg/cm². The integrated water system, with a 5 to 20 L/min flow rate, controls dust. The machines base plate is aluminum alloy, 30 to 60 cm in diameter. The total machine weight ranges from 120 to 250 kg. This tool is designed for concrete finishing with an effective 40 to 80 cm working width per pass.

Its structure features a sturdy steel frame, hydraulic suspension, and a control unit. The hydraulic system provides 80 to 200 bar of operational pressure. The grinding depth per pass is precisely adjustable from 1 to 10 mm. The diamond abrasive discs used have a 20% to 40% segment density. This machine achieves a final surface roughness of 0.2 to 5 microns. The leveling accuracy reaches ±0.5 mm over a 3-meter span. Its dust extraction system reduces PM10 particles below 0.1 mg/m³.
