Bando DXL Timing Belt

The Bando DXL timing belt is manufactured from neoprene rubber reinforced with glass fiber and polyester cords, providing high tensile strength and excellent dimensional stability. The standard pitch of the belt teeth ranges from 2.5 to 10 millimeters, and their surface is coated with nylon fabric to reduce friction and wear. The tensile strength of the belt is in the range of 80 to 110 newtons per millimeter of width, with a friction coefficient measured between 0.28 and 0.32. The operating temperature range is from -25 to +90 degrees Celsius, while heat-resistant models can operate effectively up to 110 degrees.

A key feature of the Bando DXL timing belt is its high precision in power transmission within synchronization systems at medium to high speeds. This belt provides stable operation up to 10,000 revolutions per minute, with available widths ranging from 6 to 40 millimeters. The length options vary from 150 to 1800 millimeters, and the semi-circular tooth design reduces vibration and noise levels to less than 68 decibels. These characteristics make the Bando DXL timing belt an ideal choice for precision industrial equipment and high-accuracy production lines.

Bando T10 polyurethane timing belt

The Bando T10 polyurethane timing belt is made from durable polyurethane with a standard hardness of 90 Shore A, designed for power transmission in medium to heavy-duty industrial systems. The belt features teeth spaced 10 millimeters apart, molded to ensure perfect symmetry and exact synchronization on pulleys. Internal cords are made of high-strength fiberglass, maintaining longitudinal stability and enabling the belt to withstand high loads. Belt length, width, and tooth count can be customized for diverse industrial applications, and high precision reduces slippage while improving power transmission efficiency.

This timing belt operates effectively within a temperature range of minus 30 to plus 80 degrees Celsius, maintaining stability across diverse industrial environments. Its polyurethane resistance to oils, ozone, and common chemicals extends operational lifetime. The precise tooth structure and smooth surface reduce friction and minimize noise during operation. It is primarily used in packaging machines, industrial production lines, precision equipment, and textile machinery requiring clean and accurate performance.

Bando T5 polyurethane timing belt

The Bando T5 polyurethane timing belt is made from durable polyurethane with a standard hardness of 85 Shore A, designed for power transmission in light to medium-duty industrial systems. The belt features teeth spaced 5 millimeters apart, molded to ensure perfect symmetry and exact synchronization on pulleys. Internal cords are made of strong fiberglass, maintaining longitudinal stability and allowing the belt to withstand medium loads. Belt length, width, and tooth count can be customized for diverse industrial applications, and high precision reduces slippage while improving power transmission efficiency.

This timing belt operates effectively within a temperature range of minus 30 to plus 80 degrees Celsius, maintaining stability across diverse industrial environments. Its polyurethane resistance to oils, ozone, and common chemicals extends operational lifetime. The precise tooth structure and smooth surface reduce friction and minimize noise during operation. It is primarily used in packaging machines, precision equipment, industrial production lines, and textile machinery requiring clean and accurate performance.

Bando Power Ace 5VX power transmission belt

The Bando Power Ace 5VX power transmission belt is a narrow, cogged design intended for heavy-duty, high-speed industrial applications. Its standard width is 15.9 millimeters with an approximate height of 13.5 millimeters, enabling significantly higher power transmission compared to equivalent classical belts. The belt body is made of a rubber compound resistant to oil, ozone, and heat, while the cogged profile enhances flexibility and dissipates heat efficiently. High-strength polyester tensile cords are embedded in the insulation layer to ensure stretch resistance, dimensional stability, and uniform load distribution.

This belt is manufactured in compliance with ARPM standards and operates within a temperature range of -20 to 90 degrees Celsius. Dimensional accuracy of ±0.2 millimeters guarantees consistent performance even under heavy load conditions. The narrow profile of the Power Ace 5VX allows the use of smaller sheaves while achieving higher efficiency. This belt is an ideal choice for heavy-duty industrial machinery, compressors, large fans, and high-speed power transmission systems.

Bando Power Ace 3VX power transmission belt

The Bando Power Ace 3VX power transmission belt is engineered with a narrow, cogged design to deliver higher efficiency and effective power transfer in industrial systems. Its standard width is 9.5 millimeters with a height of approximately 8 millimeters, allowing operation on smaller sheaves and enabling higher transmission ratios. The belt body is manufactured from oil and heat resistant rubber, while the cogged profile minimizes slippage and enhances heat dissipation. High-strength polyester tensile cords are incorporated to provide superior resistance to stretching and extend service life.

This belt is manufactured in compliance with ARPM standards and operates within a temperature range of -20 to 90 degrees Celsius. Dimensional accuracy is controlled at approximately ±0.2 millimeters, ensuring consistent performance under heavy loads. The narrow profile of the Power Ace 3VX allows the use of smaller sheaves while increasing power transmission capacity by up to 40% compared to classical belts. These features make it an ideal solution for high-speed industrial drives with variable loads.

Bando T2.5 polyurethane timing belt

The Bando T2.5 polyurethane timing belt is made from durable polyurethane with a standard hardness of 80 Shore A and is designed for power transmission in light-duty, precision systems. The belt features precise teeth spaced 2.5 millimeters apart, ensuring perfect synchronization and symmetry on pulleys. Internal cords are made of high-strength fiberglass, maintaining longitudinal stability throughout its service life. Belt length and width can be customized for various industrial applications, and its high precision reduces slippage while improving power transmission efficiency.

This timing belt operates effectively within a temperature range of minus 30 to plus 80 degrees Celsius, maintaining stability across diverse industrial environments. Its polyurethane resistance to oils, ozone, and common chemicals extends operational lifetime. The precise tooth structure and smooth surface reduce friction and minimize noise during operation. Its main applications include precision equipment, packaging machines, textile machinery, and production lines requiring clean and accurate performance.

Bando DH Timing Belt

The Bando DH timing belt is made of neoprene rubber reinforced with glass fiber and polyester cords, providing high tensile strength and excellent dimensional stability. The belt teeth are designed with a pitch ranging from 8 to 14 millimeters to ensure precise and uniform power transmission. Its tensile strength is measured between 90 and 120 newtons per millimeter of belt width, with a surface friction coefficient of approximately 0.3. The operating temperature range is from -20 to +100 degrees Celsius, and heat-resistant models can operate effectively up to 120 degrees.

A key feature of the Bando DH timing belt is its high positional accuracy and stable performance at high speeds. It can handle rotational speeds up to 10,000 revolutions per minute, with widths ranging from 10 to 50 millimeters. Standard belt lengths are produced between 200 and 2000 millimeters, and the tooth design reduces vibration and noise to less than 70 decibels. These characteristics make the Bando DH timing belt ideal for high-efficiency industrial machinery requiring precise power transmission.

Bando Duraflex 4L V-belt

The Bando Duraflex 4L V-belt is designed for high-speed power transmission in medium center distance drives, with common applications in HVAC systems, pumps, and household appliances. This belt has a standard width of 12.7 millimeters and an approximate height of 7.9 millimeters, allowing stable operation on small and medium-sized sheaves. Its body is made of a special rubber compound engineered for high flexibility and effective heat dissipation. High-strength polyester tensile cords are embedded in the insulation section to minimize stretching and provide uniform load distribution.

The belt features a bias-cut, rubber-impregnated fabric cover that protects internal components while enhancing resistance to oil, ozone, and heat. Its operating temperature range is specified between -20 and 80 degrees Celsius, with dimensional accuracy controlled at approximately ±0.2 millimeters. The structural flexibility of the Duraflex 4L belt ensures smooth performance on small pulleys and extends service life several times longer compared to conventional belts.

Bando DXL double-sided polyurethane timing belt

The Bando DXL double-sided polyurethane timing belt is made from high-quality polyurethane and designed for power transmission in serpentine drive systems requiring clean and quiet operation. The internal tensile cord is made of Aramid, providing very high tensile strength and minimal elongation under load. The top and bottom teeth are precision-molded to ensure full symmetry and exact synchronization between both sides. Belt length, width, and tooth count can be customized for industrial applications, and it can be used in medium to high load systems.

This double-sided timing belt operates effectively within a temperature range of minus 30 to plus 80 degrees Celsius, maintaining stability in diverse industrial environments. Its polyurethane resistance to oils, ozone, and common chemicals extends operational lifetime. Internal fiberglass cords ensure longitudinal stability and enable the belt to withstand high loads. The belt is ideal for household appliances, office equipment, and production lines requiring extremely clean and quiet performance.

Bando DT10 double-sided polyurethane timing belt

The Bando DT10 double-sided polyurethane timing belt is manufactured from high-quality polyurethane and designed for power transmission in serpentine drive systems with medium to heavy loads. The top and bottom teeth are precision-molded to ensure full synchronization and perfect symmetry between both sides of the belt. Internal cords are made of durable fiberglass, providing longitudinal stability and enabling the belt to withstand high industrial loads. Belt length, width, and tooth count can be customized to meet specific industrial requirements.

This double-sided timing belt operates effectively within a temperature range of minus 30 to plus 80 degrees Celsius, maintaining stability across diverse industrial environments. Its polyurethane resistance to oils, ozone, and common chemicals extends operational lifetime. The precise tooth design and smooth surface reduce internal friction and minimize noise during operation. The belt is ideal for household appliances, office equipment, and production lines requiring clean and quiet performance.

Bando CC Double V V-Belt

The Bando CC Double V V-Belt is manufactured from durable industrial rubber reinforced with polyester tensile cords, designed for heavy-duty power transmission in large industrial machinery. Its standard CC width and reinforced thickness enable it to handle high torque and bending stresses in multi-shaft and serpentine drive systems. The belt’s dual-direction flexibility increases service life by up to 40% compared to conventional V-belts. It operates in a temperature range of -20 to 90 degrees Celsius and provides excellent resistance to oils, greases, and heat.

The symmetric body and advanced material composition of the Bando CC Double V V-Belt reduce system vibration and prevent cracking or tearing during operation. Standard and custom lengths up to 5000 millimeters are available with ±0.2 millimeter dimensional accuracy. The tensile cords are chemically bonded to the belt body, ensuring dimensional stability and high longitudinal strength, guaranteeing reliable performance in reverse-bend and heavy-duty drive applications.

Bando DT5 double-sided polyurethane timing belt

The Bando DT5 double-sided polyurethane timing belt is made from high-quality polyurethane and designed for power transmission in serpentine drive systems. The belt features precise top and bottom teeth, ensuring perfect symmetry and exact synchronization between both sides. Internal cords are made of durable fiberglass, providing longitudinal stability under various operating conditions and enabling the belt to withstand high industrial loads. Belt length, width, and tooth count can be customized to meet diverse industrial requirements.

This double-sided timing belt operates effectively within a temperature range of minus 30 to plus 80 degrees Celsius, maintaining stability across various industrial environments. Its high polyurethane resistance to oils, ozone, and common chemicals extends operational lifetime. The precise tooth structure reduces internal friction and minimizes noise during operation. The belt is ideal for office equipment, household appliances, and production lines requiring clean and quiet performance.

Bando BX105 V-Belt

The Bando BX105 V-belt has a cross-sectional width of 17 mm and an effective length of 105 inches, designed for power transmission in medium to heavy industrial systems. It is manufactured from rubber reinforced with polyester cords, providing tensile strength up to 1200 N/cm. The narrow V-shaped profile increases pulley contact and reduces slippage, ensuring power transmission efficiency up to 97%. The belt’s operating temperature range is from -30°C to +90°C, enabling stable performance in variable environmental conditions.

The reinforcing cords of the BX105 Bando belt provide high resistance to bending fatigue and excellent flexibility, extending service life up to 10,000 operating hours under medium load. The outer layer is resistant to wear, oil, dust, and temperature variations, with the capability to withstand sudden accelerations and shock loads. This belt complies with international standards ISO 4184 and DIN 2215, making it highly suitable for precise and reliable power transmission applications.

Bando 450DH100G Industrial Timing Belt

The Bando 450DH100G industrial timing belt is a precision toothed belt designed for shaft synchronization and slip-free power transmission. The belt length is 450 millimeters, width is 100 millimeters, and the tooth pitch in the DH series is 8 millimeters. The semicircular tooth profile ensures uniform engagement and reduces mechanical noise. The use of fiberglass tensile cords and durable elastomer in the body provides dimensional stability and high endurance under cyclic loading conditions.

The Bando 450DH100G industrial timing belt can operate in temperatures ranging from minus 20 to plus 100 degrees Celsius, delivering excellent performance in heavy-duty applications. Its abrasion resistance and stability against oil and dust make it suitable for machinery with continuous duty cycles. The optimized friction surface of the teeth reduces energy consumption and extends bearing life. These features make the Bando belt widely used in packaging machines, material handling systems, and precision equipment.

Bando DL Timing Belt

The Bando DL timing belt is made of neoprene rubber reinforced with glass fiber and nylon, providing high tensile strength. The belt teeth feature a semi-circular design with a standard pitch ranging from 3 to 14 millimeters, ensuring smooth power transmission. Its tensile strength is measured between 70 and 100 newtons per millimeter of width, with an average surface friction coefficient of 0.3. The operating temperature range of the Bando DL timing belt is from -30 to +100 degrees Celsius, while heat-resistant models can perform effectively up to 120 degrees.

One of the outstanding features of the Bando DL timing belt is its high positioning accuracy in synchronization systems. This belt operates stably at high speeds up to 12,000 revolutions per minute. The available widths range from 6 to 50 millimeters, and the lengths vary from 200 to 2000 millimeters. The tooth profile is designed to generate vibration noise below 70 decibels, making it highly suitable for high-speed production lines.
