Ceiling

Gboard ceiling gypsum panel

The Gboard ceiling gypsum panel is manufactured with a lightweight core offering an approximate density of 620 to 720 kilograms per cubic meter to reduce ceiling dead load. It is commonly produced in 9.5 or 12.5 millimeter thicknesses and in dimensions of 1200 by 2400 millimeters. The panel’s longitudinal bending strength ranges from 350 to 480 newtons, providing adequate stability for suspended ceiling systems. Its high grammage facing paper ensures strong adhesion for paint and joint compound and minimizes vibration induced cracking. This panel is compatible with F47 metal ceiling frames and allows fast and low vibration installation.

The Gboard ceiling gypsum board offers a thermal conductivity of about 0.24 watts per meter kelvin and enhances thermal performance in ceiling assemblies. Its surface weight ranges from 7 to 10 kilograms per square meter, keeping grid loading within safe limits. Screw pull out resistance is approximately 230 to 280 newtons, preventing long term screw loosening. Recommended spacing for F47 profiles is 40 centimeters to avoid mid span sagging. The product is manufactured according to EN 520 type A and is ideal for residential and office interiors.

DamaTajhiz DT.CF1200 silent concealed ceiling fan coil unit

The DamaTajhiz DT.CF1200 silent concealed ceiling fan coil unit, with an airflow capacity of 1200 CFM, is designed for large office, commercial, and public spaces. It provides both cooling and heating functions with uniform airflow and ultra-low noise performance. The three-speed dynamically balanced galvanized fan and Class B electric motor minimize vibration and extend system lifespan. The copper coil with aluminum fins ensures efficient heat transfer and high thermal performance. Its low-profile and robust design allows easy installation in false ceilings and confined areas.

The DamaTajhiz DT.CF1200 fan coil unit features IP44 protection and internal thermal and acoustic insulation for safe and silent operation. The washable air filter enables quick and easy maintenance. The unit operates below 45 dB and is ideal for spaces ranging from 50 to 70 square meters. It runs on 220V single-phase power and provides suitable static pressure for short duct systems. The galvanized steel body is corrosion- and moisture-resistant, and the unit is engineered in accordance with ASHRAE international standards for optimal performance and durability.

DamaTajhiz DT.CF1000 silent concealed ceiling fan coil unit

The DamaTajhiz DT.CF1000 silent concealed ceiling fan coil unit, with an airflow capacity of 1000 CFM, is designed for medium to large residential, office, and commercial spaces. It provides both cooling and heating with uniform airflow and minimal noise. The three-speed galvanized balanced fan and Class B electric motor reduce vibration and enhance system durability. The copper coil with aluminum fins ensures efficient heat exchange and uniform temperature distribution. Its compact and slim design allows easy installation in false ceilings with limited space.

The DamaTajhiz DT.CF1000 fan coil features suitable static pressure for short duct connections and a washable air filter for convenient maintenance. The noise level remains below 42 dB, and energy consumption is optimized for efficiency. Operating on 220V single-phase power, it is ideal for areas ranging from 40 to 55 square meters. The galvanized steel casing with internal thermal and acoustic insulation enhances durability and energy performance. The unit complies with ASHRAE international standards, ensuring stable and long-lasting operation.

DamaTajhiz DT.CF600 silent concealed ceiling fan coil unit

The DamaTajhiz DT.CF600 silent concealed ceiling fan coil unit, with an airflow capacity of 600 CFM, is designed for residential, office, and medium-sized spaces. It provides both cooling and heating functions with uniform airflow and ultra-low noise operation. The three-speed galvanized balanced fan and Class B electric motor minimize vibration and extend unit lifespan. The copper coil with aluminum fins ensures high heat transfer efficiency and consistent thermal performance. Its slim and durable structure allows easy installation in false ceilings with limited space.

The DamaTajhiz DT.CF600 fan coil features IP44 protection and internal thermal and acoustic insulation for quiet and safe operation. The washable air filter allows for easy maintenance and service. The unit operates below 38 dB noise level and is suitable for areas between 25 to 35 square meters. It runs on 220V single-phase power and provides sufficient static pressure for short duct connections. The galvanized steel body is moisture-resistant and corrosion-protected, ensuring long-lasting performance and energy efficiency.

DamaTajhiz DT.CF800 silent concealed ceiling fan coil unit

The DamaTajhiz DT.CF800 silent concealed ceiling fan coil unit, with an airflow capacity of 800 CFM, is designed for residential, office, and commercial applications. This model provides stable and quiet heating and cooling performance. Its three-speed galvanized balanced fan and Class B electric motor reduce vibration and extend unit lifespan. The copper coil with aluminum fins ensures high heat transfer efficiency. Its low-profile design allows easy installation in limited ceiling spaces.

The DamaTajhiz DT.CF800 fan coil features optimal static pressure for short duct connections and a washable filter for easy maintenance. The noise level is below 40 dB, providing uniform air distribution throughout the room. It operates on single-phase 220V power and is suitable for spaces between 30 to 45 square meters. The galvanized steel housing with internal thermal and acoustic insulation enhances durability and energy efficiency. The unit is engineered according to international performance standards for long-term reliability and low energy consumption.

Damatajhiz ceiling concealed silent fan coil 200CFM model DT.CF200

The Damatajhiz DT.CF200 ceiling concealed fan coil, with an air flow capacity of 200 CFM, is designed for medium-sized residential and office spaces. This silent model provides quiet cooling and heating with minimal operational noise. The centrifugal fan features a low-noise, high-efficiency motor for reliable air circulation. The body is made from steel sheets coated with electrostatic paint resistant to moisture and corrosion. The coil pipes are made of copper with aluminum fins, ensuring fast and uniform heat transfer.

The DT.CF200 fan coil includes a washable filter to prevent dust and airborne particles from entering the indoor environment. The unit is installed concealed in a false ceiling and features adjustable air vents and manual dampers to control airflow. Overall dimensions are 650×400×220 mm, with an approximate weight of 18 kilograms. Compatibility with central control systems and room thermostats allows optimized performance and low energy consumption.

Damatajhiz ceiling concealed silent fan coil 300CFM model DT.CF300

The Damatajhiz DT.CF300 ceiling concealed fan coil, with an air flow capacity of 300 CFM, is designed for medium to large residential and office spaces. This silent model provides quiet cooling and heating with minimal operational noise. The centrifugal fan features a low-noise, high-efficiency motor for reliable air circulation. The body is made of steel sheets coated with electrostatic paint resistant to moisture and corrosion. The coil pipes are copper with aluminum fins, ensuring fast and uniform heat transfer.

The DT.CF300 fan coil includes a washable filter to prevent dust and airborne particles from entering the indoor environment. The unit is installed concealed in a false ceiling and features adjustable air vents and manual dampers for airflow control. Overall dimensions are 750×450×220 mm, with an approximate weight of 22 kilograms. Compatibility with central control systems and room thermostats allows optimized performance and low energy consumption.

Damatajhiz ceiling concealed silent fan coil 400CFM model DT.CF400

The Damatajhiz DT.CF400 ceiling concealed fan coil, with an air flow capacity of 400 CFM, is designed for large residential and office spaces. This silent model provides quiet, uniform cooling and heating. The centrifugal fan, equipped with a low-noise, high-efficiency motor, ensures stable and effective air circulation. The body is made of steel sheets coated with electrostatic paint, resistant to moisture and corrosion. Coil pipes are made of copper with aluminum fins to ensure fast and even heat transfer.

The DT.CF400 fan coil includes a washable filter to prevent dust and airborne particles from entering the indoor environment. The unit is installed concealed in a false ceiling and features adjustable air vents and manual dampers for airflow control. Overall dimensions are 850×500×220 mm, with an approximate weight of 25 kilograms. Compatibility with central control systems and room thermostats provides optimized performance and low energy consumption.

14mm ceiling screw

Ceiling screw size 14 is produced in different lengths up to 8 cm and is often used in iron and steel grades. ceiling screw 14 is produced as an automatic screw with a drill tip and does not need to be drilled with a drill for connection. Size 14 gable screws are often produced with a hex head that has a groove for connection with a double-sided wrench. However, it is also possible to connect 14 gable screws with a box wrench.
