Price: To be negotiated

Industrial Rail Sealing Machine

Exporter, Wholesale, Manufacturer
Isfahan
+989122003350

Price: Negotiate

Price :negotiated

Industrial Rail Sealing Machine , Iran

The rail sealing machine features a ST52 steel chassis with 80-micron electrostatic powder coating. Standard dimensions are 1800 x 800 x 1600 mm with a net weight of 280 kg. It utilizes a 3 kW servo motor with a precision positioning controller ±0.1 mm accuracy. Sealing speed is adjustable from 0 to 200 packages per minute via variable frequency drive. The thermal system employs a 1000W ceramic heater with PID control and 50-300°C operating range. It can seal polyethylene, polypropylene, and multilayer materials with 0.03-0.35 mm thickness.

The mechanical structure includes two parallel rails made of 6061-T6 aluminum with 25-micron hard anodized coating. Effective rail length is modularly expandable from 600 to 2000 mm. The pressure system is pneumatic with an 80 mm cylinder and 0.2-0.8 MPa working pressure. A 7-inch touchscreen HMI allows programming of 99 different sealing profiles. Power consumption is 4 kW per hour with three-phase 380V 50/60 Hz input. Sealing position repeatability is under 0.3 mm using a 2000 PPR optical encoder. All components comply with CE safety and IP65 standards for industrial environments.You can order and buy Industrial Rail Sealing Machine from Iran by contacting us through whatsaap and email.
WEBSITE: Industrial Rail Sealing Machine Iran

Factors Influencing the Purchase and Price of Rail Sealing Machines

The price of a rail sealing machine depends on the effective sealing width, rail length, and level of automation. The material of the body and rail, made from steel with anti-wear coating, directly impacts the machines durability. The type of heating system zonal or uniform and digital temperature controller PID affect sealing quality and cost. Additional features such as automatic cutting, date coding, and zipper attachment increase the price. The adjustable speed of the rail motor must align with production line capacity. The manufacturers brand and quality of electrical components like sensors and PLC influence the final price. Safety certifications CE and compliance with hygiene standards in the food industry are mandatory. Include ancillary costs such as installation, training, and consumables in your calculation. Precise alignment of the machine with actual production needs prevents unsuitable purchases and extra costs.
