masaelipacking , Iran

The Turkish delight and masgati packaging machine is constructed from 2 mm thick 304 stainless steel for direct food-contact parts. Overall dimensions are 3500 x 1500 x 1800 mm with an approximate weight of 850 kg. The system can package 30 to 50 units per minute with a weight accuracy of ±1 gram. The main drive uses a 5.5 kW servo motor and a Siemens or equivalent PLC control system. Conveyor belts feature non-stick PTFE coating with adjustable speed from 0.5 to 2 meters per second. The sealing section employs induction heating with controlled temperature from 120 to 180°C for multilayer polypropylene films.

The machine structure includes automated feeding, cutting, weighing, and sealing modules. The weighing system uses load cells with a capacity of 100 to 1000 grams and 0.1% accuracy. The cutting unit utilizes chromium-plated stainless steel blades with a frequency of 60 cuts per minute. The film wrapping system supports film rolls up to 400 mm in diameter and 450 mm usable width. Energy consumption is 10 kWh with required air pressure of 6 bar and flow of 200 liters per minute. Compliance certifications include CE, ISO 22000, and direct food-contact approval FDA.You can order and buy masaelipacking from Iran by contacting us through whatsaap and email.
