Packing machine , Iran

The cube sugar packaging machine is built from 2 mm thick AISI 304 stainless steel. Production line dimensions are 2500 x 1200 x 1800 mm with a weight of 700 kg. This machine operates at 80 to 160 packages per minute with a filling accuracy of ±0.2 grams. A 1.5 kW main servo motor controls positioning with 0.1 mm precision. A machine vision system with a 5 MP camera at 30 FPS inspects labeling and filling. Electrical power consumption ranges from 6 to 10 kW per hour.

The machine structure includes a 50 kg capacity storage hopper with a controlled flow vibrator. The weighing system uses precision load cells with 0.05 gram accuracy and 99.8% repeatability. The dual-side heat sealing unit operates at adjustable temperatures of 150 to 230°C. Multilayer packaging film PET/AL/PE with 150-250 mm width and 40-80 micron thickness is supported. The entire system is managed by a PLC controller and a 10-inch touchscreen with Ethernet port. Preventive maintenance includes an automatic lubrication system and wear sensor alarms.You can order and buy Packing machine from Iran by contacting us through whatsaap and email.
WEBSITE: Packing machine Iran
