Gas Hob Iran

Gas Hob

The built-in Model GS2013 cooktop is made from 0.8 mm thick 430 stainless steel. Its standard cutout dimensions are 780 x 450 mm with a frame depth of 25 mm. This model features four burners with diameters of 65, 75, 85, and 100 mm. Their thermal power ratings are 2500, 3000, 3500, and 4000 watts respectively. The average combustion efficiency of this model reaches 56%. It is equipped with an automatic electronic ignition system and a digital LED display.

Thermocouple safety valves are designed with a 10-second cut-off delay for safety. The burners are constructed from aluminum alloy with anti-corrosion ceramic coating. The control panel is stainless steel with a moisture-resistant touch panel and clear indicators. Base insulation uses ceramic wool with a density of 140 kg/m³. The cast iron grates feature a matte epoxy coating resistant to temperatures up to 850°C. A four-point mounting system with adjustable metal clips ensures a secure connection.

Gas Hob

The built-in Model IG3603 cooktop is made from 0.7 mm thick 430-grade stainless steel. Its installation frame dimensions are 590 x 510 mm with a 28 mm frame depth. This model is equipped with three burners with diameters of 70, 80, and 100 mm. Their thermal power ratings are 2900, 3300, and 3700 watts respectively. The overall combustion efficiency of the appliance reaches 54%. The electronic ignition system uses a piezo source with a battery backup.

The safety valves are thermocouple type with a maximum cut-off delay of 15 seconds. The angled control panel is made of steel with laser-engraved indicators. The burners are coated with a refractory ceramic layer on an aluminum alloy base. The base insulation is ceramic wool with a density of 110 kg/m³. The cast iron grates have a scratch-resistant black epoxy coating, tolerant up to 800°C. The mounting system includes four locking steel clamps for secure attachment.

Gas Hob

The built-in Model IG3652 cooktop is constructed from 0.7 mm thick 430 stainless steel. Its standard cutout dimensions are 580 x 520 mm with a frame depth of 35 mm. This model features three burners with diameters of 75, 95, and 120 mm. Their thermal power ratings are 2800, 3400, and 4000 watts respectively. The average combustion efficiency of this design is improved to 55%. The automatic electronic ignition system is equipped with dual piezo cells.

The thermocouple safety valves feature a 10-second gas cut-off delay. The control panel is made of polished steel with deep laser engraving. The burners are constructed from aluminum alloy with airfoil channels for optimal mixing. The base thermal insulation uses rock wool with a density of 130 kg/m³. The cast iron grates have a refractory ceramic coating resistant to 850°C. The mounting mechanism includes six locking stainless steel clamps for full security.

Gas Hob

The Ilia Steel gas cooktop features four burners made from 430-grade stainless steel sheet, 0.6 mm thick. Its overall dimensions are 600 x 550 mm with a height of 120 mm. Each burner provides a thermal power of 3500 watts with a combustion efficiency of 52%. The auto-electronic ignition system operates on 12V DC. The cast iron grates are 120 mm in diameter and 5 mm thick. These grates withstand operational temperatures up to 700 degrees Celsius.

The internal chamber structure is lined with a 20 mm thick rock wool insulation layer. This insulation keeps the external surface temperature below 60 degrees Celsius. The safety valves have a nominal flow rate of 0.5 cubic meters per hour. The control panel is made of glass-reinforced polyamide. This panel withstands temperatures up to 120 degrees Celsius. Adjustable feet provide up to 15 mm of height adjustment. This design enables precise leveling on uneven surfaces.

Gas Hob

The tabletop Model IG4655 cooktop is made from 0.8 mm thick 430-grade stainless steel sheet. Its compact dimensions are 460 x 450 mm with a height of 120 mm. This model features two burners with effective diameters of 75 mm and 100 mm. The small burners thermal power is 2600 watts and the large one is 3200 watts. Its combustion efficiency is calculated at 50 percent. The ignition system is a mechanical piezo type with a 6 mm spark length.

The body structure features a 15-degree rolled edge to prevent liquid spillage. The burners are made from aluminum alloy with a hard anodized oxide coating. The cast iron grates have a diameter of 110 mm and a thickness of 4 mm. The control panel is steel with permanent laser-engraved indicators. Ceramic insulating feet keep the underside surface temperature below 65°C. The gas control valves are dual-axis type with a nominal flow rate of 0.4 m³/h.

Gas Hob

The Model IG4613 cooktop is constructed from 0.7 mm thick 430-grade stainless steel. Its dimensions are 460 x 400 mm with a height of 110 mm. This product features a single burner with an effective diameter of 100 mm. This single burner provides 3000 watts of thermal power with 48% combustion efficiency. The ignition system uses a direct-impact piezoelectric mechanism. The cast iron grate has a diameter of 120 mm and a thickness of 4.5 mm.

Its single-burner structure includes an optimized combustion chamber for even heat distribution. The body features a scratch-resistant coating with a pencil hardness of 3H. The gas control valve is a rotary type with precise gradation for flame adjustment. Heat-resistant silicone rubber feet, tolerating up to 250°C, are installed. These feet prevent heat transfer to the underlying surface. The products net weight is 2.8 kg for easy portability.

Gas Hob

The IG5955 model cooktop is made of 430-grade stainless steel with a gold PVD coating. Its precise dimensions are 595 x 510 mm with a height of 135 mm. The top plate thickness is 0.7 mm with an anti-fingerprint coating. It features two large burners at 3800 watts and two small burners at 2800 watts. The average combustion efficiency of this model reaches 54%. The combustion system includes a thermocouple with a 10-second gas cut-off delay.

The internal structure features a 25 mm thick ceramic wool thermal insulation layer. This insulation keeps the side body temperature below 50 degrees Celsius. The burners are made from aluminum alloy with anti-corrosion ceramic coating. The piezo ignition system produces an 8 mm spark arc length. The cast iron grates are 140 mm in diameter with an anti-rust enamel coating. Adjustable height feet allow for precise leveling up to 20 mm.

Gas Hob

The built-in Model 3603 cooktop is constructed from 430 stainless steel, 0.6 mm thick. Its standard cutout dimensions are 600 x 520 mm with a frame depth of 30 mm. This model features three burners with diameters of 70, 80, and 100 mm. Their thermal power ratings are 2800, 3200, and 3600 watts respectively. The average combustion efficiency of this design reaches 53%. The ignition system is electronic, powered by a 1.5V lithium battery.

The gas safety valves are thermocouple type with a 12-second cut-off delay. The angled control panel is made of steel with permanent ceramic printing. The burners are made from pressure-cast aluminum with optimized air channels. The base insulation uses rock wool with a density of 120 kg/m³. The cast iron grates feature heat-resistant epoxy coating, tolerating up to 750°C. Adjustable steel feet ensure even and secure installation.

Gas Hob

The Model IG2303 cooktop is made from 0.6 mm thick 430-grade stainless steel sheet. Its compact dimensions are 300 x 280 mm with a height of 95 mm. This model features two burners with effective diameters of 65 mm and 85 mm. The small burners thermal power is 2200 watts and the large one is 2800 watts. The appliances combustion efficiency is calculated at 47 percent. The ignition system is a mechanical piezo type designed for direct connection.

Its structure features an integrated combustion chamber for increased rigidity. The body has a brushed satin finish with high corrosion resistance. The cast iron grates are 100 mm in diameter with a matte enamel coating. The control valves are rotary type with clear position indicators. Four thermal insulating rubber feet prevent heat transfer to the surface. The final product weight is only 2.1 kg for fully portable use.
