Label Date and Information Printer
This device utilizes a direct thermal or thermal transfer printing mechanism. Printing speeds range from 150 to 300 mm per second with resolutions of 203 or 300 DPI achievable. It prints on paper, synthetic, and polyester labels with widths of 50-100 mm and lengths of 10-300 mm. The ribbon supply for thermal transfer has an 83 mm diameter core and a 450-meter length capacity. Print positioning accuracy with a linear encoder system is ±0.2 mm. A label gap sensor and mark sensor with a 0.5 ms response time are integrated.
The structure features an anodized aluminum body and a steel frame with overall dimensions of 300x200x250 mm. The label feeding system is roll-based, supporting a maximum 200 mm roll diameter with automatic tension control. The user interface includes a 4.3-inch color touchscreen for programming dates, barcodes, and graphics. Printed label output is configurable with an automatic cutter or a peel-off separation mechanism. Communication interfaces include USB, Ethernet, and RS-232 serial ports for integration with existing control software. The device operates on 24V DC input with 60W power consumption and is manufactured in compliance with FCC and RoHS standards.
