Elevator button , Iran

An elevator push button panel is an electrical command device for registering floor calls and managing control signals in car and hall stations. Standard supply voltage ranges from 12 to 30 volts DC with circuit current below 60 milliamperes. The printed circuit board is manufactured from 1.6 millimeter FR4 with 35 micron copper cladding. Contact resistance is under 40 milliohms, and electrical life exceeds 500 thousand cycles. Enclosure protection ranges from IP44 to IP65 with minimum IK09 impact resistance. Dielectric withstand capability is verified at 1500 volts AC without breakdown.

The assembly includes an anti scratch stainless steel push switch or capacitive touch sensor with EMI noise filtering circuitry. Mechanical operating force ranges from 1.5 to 4 newtons with travel of 0.5 to 1 millimeter. Button diameter varies between 19 and 35 millimeters with installation tolerance below ±0.1 millimeter. LED luminous intensity ranges from 80 to 200 candela with service life above 50 thousand hours. Communication with the controller is implemented through serial protocols such as RS485 or CAN. Quality validation includes vibration testing, 95 percent humidity exposure, and 1 million operational cycle endurance tests.You can order and buy Elevator button from Iran by contacting us through whatsaap and email.
