industrial machine , Iran

This machine is constructed from ST37 steel with a 60-micron epoxy coating for corrosion resistance. Overall dimensions are 2200 x 850 x 1500 mm with an approximate weight of 320 kg. The main servo motor provides 2.2 kW power and adjustable speed control from 0 to 250 seals per minute. The date coding system uses thermal transfer with adjustable temperature from 50 to 200°C and 0.1 mm resolution. It can seal HDPE, LDPE, and PP plastics with thicknesses from 0.02 to 0.2 mm. Sealing pressure is adjustable from 0.3 to 0.8 MPa with ±0.02 MPa accuracy.

The machine features two parallel anodized aluminum rails with a hardness of 60 Rockwell B. Rail length is adjustable from 500 to 1500 mm with a 10 mm movement increment. The sealing head includes an 800-watt ceramic heater with PID control for ±2°C temperature stability. The date coder supports 6 programmable characters for date and time settings up to the year 2050. Power consumption is 3.5 kW per hour with three-phase 380V ±10% input. Sealing positioning accuracy uses a 1000 PPR optical encoder with less than 0.5 mm error. All electrical components are designed to IP54 standards for dust and moisture protection.You can order and buy industrial machine from Iran by contacting us through whatsaap and email.
