Price: To be negotiated

Packing machine

Exporter, Wholesale, Manufacturer
Isfahan
+989122003350

Price: Negotiate

Price :negotiated

Packing machine , Iran

The hookah mouthpiece packaging machine is built from ST52 carbon steel with industrial epoxy coating. It measures 1800 x 900 x 1600 mm with a net weight of 420 kg. The system operates at 30 to 50 packs per minute for plastic tubes. A ceramic heating element with 2.2 kW power and controlled temperature of 150-180°C performs sealing. A main axis servo motor with 0.05 mm repeatability precision controls the motion. It operates on 380V three-phase, 50 Hz power with a consumption of 3.5 kW.

The feeding mechanism is a vibratory type with a 304 stainless steel bowl. The sealing system uses metallized polypropylene film with a width of 250 mm. Inductive proximity sensors with 100 Hz frequency track tube position. The heat press pressure is adjustable between 2 to 5 bar for secure packages. The loading hopper has a capacity of 2000 tubes for continuous production. The machine features a forced air cooling system to extend heater life.You can order and buy Packing machine from Iran by contacting us through whatsaap and email.
WEBSITE: Packing machine Iran

Hookah Accessories Production and Packaging Line

The hookah accessories production line includes stages of manufacturing, finishing, quality control, and packaging. First, ceramic, metal, and glass components are produced or prepared in the manufacturing section. Then, in the finishing and glazing stage, the product surface is polished and decorated. Packaging is the final and crucial stage for customer appeal and product protection. Automatic or semi-automatic machines are used for packaging. The machines must have anti-scratch packaging capability using protective films like bubble wrap, foam, or specialty cardboard. Multipack systems are used for packaging complete hookah sets. Insertion of instruction cards, brochures, and silica gel packets into the package is also performed by the machine. Visual quality control and leak testing on the line provide final assurance.
