Packing machine , Iran

The automatic date coding machine is constructed from 6061-T6 aluminum and hardened steel components. It is powered by a 400-watt servo motor and a 1000-pulse optical encoder. Operating speed reaches 120 marks per minute with positioning accuracy of ±0.05 mm. The marking head is a pneumatic impact type with 0.6 MPa working pressure and 300 N impact force. Impression depth is adjustable from 0.1 to 1.5 mm on metal, plastic, and cardboard surfaces. The machine handles materials from 0.1 to 5 mm thickness and production line widths up to 300 mm.

The control system features a PLC with a 7-inch touchscreen display and 500 pattern memory. The feeding mechanism uses a conveyor belt with adjustable speed from 0.5 to 5 meters per minute. It includes Ethernet connectivity and remote programming capabilities. Power consumption is 1.2 kW in operational mode with CE and UL certifications. Machine dimensions are 800 x 600 x 400 mm with a weight of 85 kg. It can be integrated into production lines with minimal modification and setup time under 2 hours.You can order and buy Packing machine from Iran by contacting us through whatsaap and email.
WEBSITE: Packing machine Iran

How an Automatic Date Coding Machine Works

An automatic date coding machine starts by automatically detecting packages on the conveyor. Sensors optical, inductive, or mechanical identify the exact package position and send a signal to the central control system PLC. The PLC issues a print command to the printing mechanism inkjet, thermal, impact. In inkjet printers CIJ/DOD, ink is ejected under pressure as charged droplets and deposited on the surface via electrostatic deflection. In thermal printers TTO, a heating element melts the ribbon, transferring information onto the surface. In impact printers, a plate makes contact with the surface using pneumatic or electromechanical pressure. Precise timing synchronization between package movement and the printing action is essential to prevent smudging or text misplacement. This machine can print variable information such as date, barcode, and serial numbers with high accuracy and speed.
