Price: To be negotiated

packing machine

Exporter, Wholesale, Manufacturer
Isfahan
+989122003350

Price: Negotiate

Price :negotiated

packing machine , Iran

The airline pack packaging machine is built from 304 stainless steel with an antistatic coating. It measures 2500 x 1200 x 1800 mm with a net weight of 650 kg. The system can achieve a vacuum down to 0.1 bar absolute in a 400 x 300 mm chamber. The full packaging cycle varies between 25 to 40 seconds depending on product volume. A two-stage oil-sealed vacuum pump with 5.5 kW power is the core of the system. It utilizes a compressed air network at 6 bar with a consumption of 50 liters per minute.

A PLC control system with a 10-inch HMI interface manages all parameters. A 2 kW heating element with adjustable temperature from 100 to 200°C performs sealing. Feed rollers handle multi-layer nylon-polyester film with a width of 550 mm. Differential pressure sensors with ±0.5% accuracy ensure the required vacuum level. The machine features an audible and visual alarm system for process faults. Its production capacity reaches 120 packs per hour with 98% efficiency.You can order and buy packing machine from Iran by contacting us through whatsaap and email.
WEBSITE: packing machine Iran

Key Considerations for Purchasing Vacuum and Protective Packaging Machines for Flight Kits

This machine is designed for sterilizing and protecting flight kits from moisture, dust, and damage. When purchasing, note the internal chamber dimensions to ensure compatibility with the maximum flight kit size. The vacuum pump capacity in CFM or m³/h must be capable of creating a deep and stable vacuum. A controlled hot air temperature system is essential for effective sterilization. The chamber material and internal surfaces should be made of corrosion-resistant stainless steel and tolerant of chemical disinfectants. Medical and safety standard certifications such as ISO 13485, CE Medical Class, and aviation authority approvals are mandatory. A reporting and parameter logging system for each cycle is critical for quality tracking and audits. Specialized after-sales service and operator training are absolute necessities due to the sensitive application.
