masaelipacking , Iran

The Mishka packaging machine is constructed from 1.5 mm thick 304 stainless steel for food-contact surfaces. Overall dimensions are 3000 x 1200 x 1700 mm with an approximate weight of 650 kg. The system can package 40 to 60 units per minute with a weight accuracy of ±0.5 grams. The main drive uses a 4 kW servo motor and an Omron or equivalent PLC controller. Conveyor belts feature food-grade silicone coating with adjustable speed from 0.3 to 1.5 meters per second. The sealing section employs induction heating at 100–150°C for metallized polyester films.

The machine structure includes feeding, aligning, weighing, and dual-side sealing modules. The weighing system utilizes load cells with 50 to 500-gram capacity and 0.05% accuracy. The forming unit uses interchangeable stainless steel molds for various product dimensions. The film wrapping system supports film rolls up to 350 mm in diameter and 400 mm usable width. Energy consumption is 7.5 kWh with required air pressure of 5 bar and flow of 150 L/min. Compliance certifications include CE, ISO 22000, and direct food-contact approval FDA.You can order and buy masaelipacking from Iran by contacting us through whatsaap and email.
