elevator cabin

Exporter, Wholesale, Manufacturer
Tehran_North
+989122003350

Price: Negotiate

Price :negotiated

elevator cabin , Iran

The elevator car is constructed from aluminum composite panels with high-density polyethylene core or galvanized steel sheets, 2–4 mm thick. Standard internal dimensions range from 1100x1400 mm to 2400x2800 mm with ceiling heights of 2200–2800 mm. Load capacity varies from 450 to 6300 kg, designed with a 1.25 safety factor per EN 81-20 standards. The car floor uses porcelain ceramic tiles 10 mm thick with anti-slip coating achieving a friction coefficient of 0.8. Interior walls are clad with 316Ti stainless steel sheets 1.5–3 mm thick featuring brushed or patterned finishes. All joints utilize A4-80 marine-grade stainless steel bolts and silicone elastomer seals to reduce noise below 20 decibels.

The car frame consists of welded steel profiles with 355 MPa yield strength and 80-micron polyurethane epoxy coating. The suspension system includes four to twelve guide shoes with carbon-reinforced PTFE composite material for friction coefficients below 0.05. The car door is a two-panel automatic type with a 180W synchronous motor, opening speeds of 0.3–0.75 m/s, and 3D laser safety sensors. The car roof features a 700x900 mm safety hatch supporting 250 kg weight and integrated 56V LED lighting with adjustable color temperature 2700–6500 Kelvin. The floor integrates load cells with ±0.1% accuracy and an automatic re-leveling system with ±0.5 mm precision. Manufacturing complies with EN 13501-2 smoke control, ISO 4190-5 testing, and ASME A17.1/CSA B44 safety certification standards.You can order and buy elevator cabin from Iran by contacting us through whatsaap and email.
WEBSITE: elevator cabin Iran

Correct Method for Maintaining and Cleaning an Elevator Cabin

Regular elevator cabin maintenance includes weekly cleaning and visual inspection. For interior surfaces, use a mild soap and water solution and a soft cloth. Avoid strong chemicals, abrasives, or solvents on panels and mirrors. Sweep the cabin floor regularly and disinfect it with an appropriate solution. Doors and door gears should be dusted and lubricated monthly. Clean lighting systems and displays with a dry, non-abrasive cloth without pressure. If an air ventilation system is present, its filter should be checked or replaced every three months. For cleaning the emergency exit or rescue window, always lock out the system and seek assistance from a certified technician. These measures extend the cabins service life and reduce repair costs.
