361-1402 pressure switch

The 361-1402 pressure switch is a mechanical industrial pressure control device designed for monitoring and regulating pressure in hydraulic, pneumatic, and process systems. It features an adjustable pressure range from 2 to 16 bar, with a precise setpoint adjustment screw. The contact type is SPDT, rated at 5A and 250V AC. The housing is made of nickel-plated brass, while the diaphragm is constructed from AISI 316 stainless steel for resistance to corrosive fluids and high pressure. The unit provides IP65 protection, ensuring reliable operation in demanding industrial environments.

The 361-1402 pressure switch operates within a temperature range of -20°C to +80°C and has a response time of less than 10 milliseconds. It features a G1/4 female process connection and an electrical output via a DIN EN 175301-803-A connector. The mechanical life expectancy exceeds one million switching cycles. Designed in accordance with CE and IEC 60947 standards, this model is ideal for use in pump control systems, compressors, pressure vessels, and process pipelines.
