TENSIONING PULLY 1013 , Iran

The Model 1013 belt tensioner is manufactured from ADC12 aluminum alloy using high-pressure die casting. Its pulley is made from ST52 steel with a carburizing treatment achieving a surface hardness of 55 to 60 HRC. The mechanism includes an M10x1.25 adjustment screw with a dacromat coating and a lock washer. This screw can apply a linear tension force between 280 and 350 Newtons. The main bearing is a shielded deep groove type, model 6202-2Z, with radial play under 0.005 mm. The pulleys outer diameter is 75 mm with five grooves conforming to ISO 9981-PK standards. The assemblys effective operating temperature ranges from -30 to +110 degrees Celsius.

The units structure consists of a main housing, a pivoting arm, and a pivot pin made from hardened CK45 steel. The pulley is attached to the arm with three M6x1 screws torqued to 12±2 Nm. The system incorporates a steel coil spring with a 3 mm wire diameter and 12 active coils. This spring provides a torsional torque of 8 Nm to maintain dynamic tension. The maximum permissible pulley speed is 7500 RPM with a radial load capacity of 190 Newtons. The bearings designed lifespan under variable radial loads extends to 3500 hours of continuous operation.You can order and buy TENSIONING PULLY 1013 from Iran by contacting us through whatsaap and email.
