Search Results For Liftruck

liftruck pump

The forklift steering pump is a fixed-displacement, pressure-compensated gear type. Its output flow ranges from 8 to 25 L/min at 1500 RPM. Its maximum operating pressure reaches 160 bar. The pump body is made from hard-anodized aluminum alloy. The gears are constructed from case-hardened steel with 60 HRC surface hardness. Gear backlash is maintained below 0.02 mm. It features an internal relief valve with ±3 bar adjustment accuracy. Its volumetric efficiency under nominal conditions exceeds 92%. This pump can operate with hydraulic oil having 15 to 46 cSt viscosity.

The pump input shaft is made from hard chrome-plated carbon steel. This shaft is designed to DIN 5480 standard. Axial sealing is provided by a mechanical seal with a 5000-hour lifespan. The permissible operating temperature ranges from -40°C to 120°C. Generated noise level at one meter is below 70 dB. The pump requires a 125-micron suction filter at the inlet. Its standard ports are UNF or metric with O-Ring seals. It connects directly to the forklift engine via a flexible coupling. Its design is compatible with orbital hydraulic steering systems requiring 60 Nm torque.


dizel-part	021-55410365

hydraulicpaytakht

Iran

021-55770712

liftruck pump

The FD50 forklift hydraulic pump is typically a high-performance two-stage vane pump. It is designed to provide high flow at low pressure and reduced flow at high pressure. Its nominal first-stage flow reaches 60 liters per minute at 40 bar pressure. The second stage delivers 25 liters per minute at an operating pressure of 150 bar. The maximum allowable system pressure is limited to 180 bar. This pump is directly driven by the forklifts diesel or gasoline engine at 2000 to 2400 RPM. The two-stage operation enables faster lifting and lowering cycles.

The pumps structure consists of an aluminum housing, a steel rotor, vanes, and cam rings. The vanes are made from hardened steel with a high surface finish. The pump dimensions are approximately 35 cm in length and 20 cm in diameter. Its weight is around 15 kilograms. It utilizes a through-flow oil cooling system. Internal check valves control the transition between the two pumping stages. Its design is suitable for operating temperatures up to 80 degrees Celsius. This pump is the core of the hydraulic system in 5-ton capacity cushion tire forklifts.
