Connecting Link Iran

size 8 connecting link

The steel chain connector size 8 and 10 is a critical component in industrial lifting and load handling systems. It is designed for secure connection of steel chains used in manual hoists, overhead cranes, and pulling equipment. The nominal sizes 8 and 10 millimeters indicate the compatible chain diameter. These connectors are typically manufactured from high strength alloy steel and offer working load limits ranging from 2 to 6.3 tons. A minimum safety factor of 4 to 1 is maintained. The engineered design ensures uniform stress distribution and reduces load concentration at connection points.

Structurally, the steel chain connector features a forged body with precise heat treatment. Surface finishes include industrial paint, galvanization, or wear resistant coatings. These connectors provide high resistance to abrasion, impact, and mechanical fatigue. Their use significantly improves lifting system safety. Steel chain connectors size 8 and 10 are widely applied in construction, heavy transportation, mining, and industrial workshops. Fast installation and reliable performance are key advantages of this industrial component.

chain connecting link

The double-end chain link is a heavy-duty mechanical connector designed to simultaneously attach two chains or cables to a load or lifting system. Dimensions typically range from 20 mm to 120 mm, with load capacities from 0.5 to 15 tons depending on size and material. The link is made of alloy steel with heat treatment, providing high resistance to tension, impact, and wear. The surface is coated with galvanized layer or epoxy paint for long-term protection against corrosion, moisture, and harsh environmental conditions.

Structurally, the double-end chain link features two loops or jaws for attaching chains on each side, with strong bolts to secure them. The design ensures uniform force distribution, reduces concentrated stress on the chains, and prevents slippage or damage. The double-end chain link is optimized for cranes, industrial hoists, load handling, and heavy-duty industries, manufactured according to ISO 1834 and EN 1677 standards to ensure safety, durability, and long-term performance.

6mm connecting link

The chain connector is a mechanical piece similar to one of the chain beads, with the difference that it is separated by a pin in the middle and allows the chain strands to be connected. The chain connector is produced in a simple form and in the form of a quick connection, which is used for small chain sizes and under low tensile stresses, and has a screw. The chain link suitable for the chain size from 6 mm to 22 mm can be supplied in Draco Towing markets. The connection of the steel chain produced with the G80 grade is used in the connections of the load-bearing steel chains.
Different brands have produced steel chain connectors, which use different techniques to perform thermal hardening operations in order to increase the tensile tensile capabilities.

Galvanized connecting link

To connect different strands of chain to each other or to connect chains to other lifting tools, a piece is needed that acts like a chain but has the ability to open and separate. The steel chain connector actually provides the ability to connect two chains of different sizes to each other or to connect the chain to the hook, hook or sling ring without any problems.
The steel chain link consists of a curved main body, which is produced by hot forging method. G80 grade steel is often used in the production of this body, which has both a medium and high percentage of carbon in the steel alloy, and its mechanical capabilities have increased during hard work.

dia10 connecting link

As the name suggests, the chain connecting link is used to establish a connection between a chain with sling connections or two chains. Two different forms of chain link are produced, one is produced in two pieces with a rod and the other is produced like a chain bead with a connecting screw that opens and closes the ring. In heavy applications, only the first type, the two-piece oval steel chain connecting link, is used to connect chain slings.

connecting link

Connecting link is a type of chain rigging that is used to coonnect two strings of lifting chain or other chain accessories. there are two different kinds of connecting link including standard and quick link.
