microswitch model 281708-V7

The microswitch model 281708-V7 is a precision mechanical switch with a durable industrial-grade structure used for position control, motion detection, and circuit limitation in automation systems. It features a snap-action mechanism with an actuation angle below 15 degrees and a mechanical lifespan exceeding 10 million cycles. The housing is made of glass fiber reinforced polyamide, providing IP67 protection against moisture and vibration. Its operating temperature range is from -25 to +85 degrees Celsius, and it supports a rated current of 10A at 250V AC. The switch measures 27×16×50 mm and weighs approximately 38 grams.

This microswitch includes a spring-loaded metal lever with a stainless steel roller for smooth and precise operation, suitable for industrial applications such as robotics, conveyor systems, and door control units. Its screw-type brass terminals with nickel plating ensure high electrical conductivity and corrosion resistance. The contact gap is about 0.4 mm with a response time below 5 milliseconds. The 281708-V7 complies with EN61058 and UL508 international standards and is designed for panel or bracket mounting using M3 screws.
