Cabinet Shrink Packaging Machine , Iran

The cabinet shrink machine is constructed from an epoxy-coated steel frame and 304 stainless steel panels. The internal heat tunnel dimensions are typically 600 x 500 x 400 mm, customizable up to 1500 x 1000 x 800 mm. Ceramic heating elements with 9–36 kW power and adjustable temperature of 50–350°C are utilized. The conveyor system is a Teflon mesh belt with widths of 300–1000 mm and variable speed of 0–15 m/min. It can process 10–30 packages per minute depending on product size and film type. Energy consumption ranges from 15–45 kWh with required air pressure of 6 bar.

A digital PID temperature control system with ±1°C accuracy and a 7-inch touchscreen display is installed. Forced air circulation using 0.5 kW centrifugal fans ensures even heat distribution. Safety features include optical sensors and a self-locking door with automatic heat cut-off. It is compatible with PE, PVC, and POF shrink films with thicknesses of 15–50 microns. External dimensions range from 1200 x 1000 x 1500 mm to 2500 x 2000 x 2200 mm. The machine complies with CE and UL standards and is manufactured under ISO 9001 certification.You can order and buy Cabinet Shrink Packaging Machine from Iran by contacting us through whatsaap and email.
