Printing Wood , Iran
- Price :To negotiate
- order by whatsapp
This machine is a piezoelectric inkjet printer with a resolution of 1440 x 1440 DPI. The print head moves over the wood surface with 10-micron positioning accuracy. It uses water-based inks containing 20% UV-resistant pigments. These inks penetrate 0.2 mm deep into the wood substrate. Maximum print dimensions are 2500 x 1300 mm with workpiece thickness up to 100 mm. A plasma pre-treatment system optimizes the wood surface for ink adhesion. This process reduces the surface contact angle to below 30 degrees.
The machine structure features a vacuum table with 80 kPa suction for complete part stabilization. Post-printing, a UV-LED curing system at 385 nm wavelength and 240 W/cm power dries ink in 3 seconds. This method increases abrasion resistance of the print to 4H pencil hardness. Print speed in high-quality mode is 15 square meters per hour. Print position repeatability accuracy is within ±0.1 mm. All ink-wetted parts are made of 316 stainless steel or PTFE. The machine can print on raw wood, MDF, and particle board.You can order and buy Printing Wood from Iran by contacting us through whatsaap and email.
WEBSITE: Printing Wood Iran
Key Points in Wood Grain Printing Services
Wood grain printing services are performed using techniques such as transfer printing, UV printing, and sublimation. The choice of printing technique depends on the substrate material MDF, particleboard, natural wood, design size, and usage environment. Print resolution must be high typically at least 600 DPI to realistically reproduce wood details and texture. Surface preparation with wood-specific primers is essential for better adhesion and preventing ink absorption. Design fixation with protective UV topcoats or varnish enhances resistance to scratches, moisture, and UV rays. Color calibration of devices is critical for accurate matching with the clients color sample. Checking eco-friendly certifications of inks and coatings is important for indoor applications. Conducting durability tests against abrasion and light before final delivery is recommended.
