accumolator , Iran
A diaphragm accumulator is a hydraulic pressure vessel that stores fluid energy by separating nitrogen gas from oil. Tank capacity ranges from 0.5 to 20 liters, with working pressure between 50 and 350 bar. The diaphragm is made of NBR or Viton rubber, resistant to temperatures up to 120°C, and supports over 500,000 pressure cycles. Charging valve and safety vent comply with ISO 4126-1 standards. Initial nitrogen pressure is adjustable from 20 to 100 bar, ensuring volumetric efficiency above 95 percent.
Structurally, the body is steel or stainless steel with 4 to 8 mm thickness and anti-corrosion coating. Inlet and outlet flanges are threaded or quick-connect per ISO 6162. The accumulator reduces hydraulic shock and controls pressure peaks. Device weight varies from 5 to 50 kg depending on capacity, and it is suitable for high-pressure hydraulic lines up to 350 bar. These specifications are optimized for industrial machinery and advanced hydraulic systems.You can order and buy accumolator from Iran by contacting us through whatsaap and email.
WEBSITE: accumolator Iran
Key Points in Purchasing and Pricing a Diaphragm Accumulator from iran
When purchasing a diaphragm accumulator, volumetric capacity, operating pressure, and hydraulic fluid type are critical. Nominal pressure typically ranges from 10 to 350 bar, and tank volume from 0.1 to 10 liters. Diaphragm material NBR, Viton, or PTFE directly affects wear and temperature resistance. Installing a safety valve, pressure gauge, and proper filter increases system lifespan and safety. Price depends on capacity, material, brand, and after sales service. Proper selection based on cycles per hour and operating temperature reduces wear and energy consumption.
