1-32 polyethylene branch saddle fitting

32x1 inch Polyethylene Branch Saddle Fitting Specifications

This female adapter fitting is made of polypropylene copolymer PP-C with size 1"×32mm, designed for branching in pressurized piping systems. The high-pressure threaded connection ensures leak-proof performance up to 10 ATM working pressure.

*Main technical specifications of 1"×32mm polyethylene branch saddle:

Size: 1" × 32mm

Material: Polypropylene copolymer PP-C

Working pressure: 10 ATM PN10

Connection type: High-pressure threaded

Thread type: Female 32mm × 1" BSP

Temperature range: -20°C to +95°C

For optimal performance, it is recommended to use appropriate PTFE tape for thread sealing and install with 35-40 Nm torque. The 32x1 inch polyethylene branch saddle is not recommended for gas transmission lines and is primarily used in water supply, industrial, and chemical systems. Its high chemical resistance makes it suitable for use with a wide range of fluids.

If you
e looking for high-quality 32x1 inch polyethylene branch saddles, you should consider the raw material quality, production standards, and product warranty. This fitting is available in both single-wall and double-wall versions, allowing you to select the best option according to your project requirements.
