Industrial Stacker , Iran

Modern industrial stackers are engineered with a nominal load capacity ranging from 800 kg to 1500 kg and a load center distance of 400 mm to 600 mm . These machines feature a compact chassis with a wheelbase of approximately 810 mm to 1510 mm, enabling a tight turning radius between 1250 mm and 1786 mm . The drive system is typically AC electric with a 1.5 kW to 1.6 kW drive motor, while the lift mechanism utilizes a 2.2 kW to 3 kW motor . The standard lift height reaches 3000 mm to 3300 mm, customizable up to 5000 mm, with a lowered mast height under 2061 mm for doorway clearance . The service weight varies by capacity, starting from 1760 kg, and a ground clearance of 116 mm at the wheelbase center ensures smooth operation on uneven surfaces .

The structural design prioritizes space optimization and operational durability, featuring electromagnetic braking systems and efficient hydraulic pumps . Engineering calculations adhere to international standards like EN ISO 3691-5 for stability and safety . Fork dimensions are configurable with thicknesses of 35 mm to 60 mm and lengths of 900 mm to 1150 mm, with adjustable fork spacing to accommodate European pallets 1100×580 mm . Power is supplied by a 24-volt battery system with a 210 Ah capacity, available in lead-acid or lithium-ion configurations, enhancing runtime and reducing maintenance . The acoustic emissions are capped at a maximum of 74 dBA, aligning with workplace ergonomic standards .You can order and buy Industrial Stacker from Iran by contacting us through whatsaap and email.
