TNMG22 lathe insert for steel

The TNMG22 turning insert for steel is made of tungsten carbide with a surface hardness exceeding 2600HV, ideal for machining alloy and hardened steels. The insert has a cutting edge length of 12.7 mm, thickness of 4.76 mm, and a nose radius of 0.8 mm, which improves chip control and machining accuracy. The rake angle is 15 degrees and the clearance angle is 7 degrees, designed to increase tool life and enhance final surface quality. The TiAlN coating offers heat resistance up to 900°C, increasing wear resistance and extending the insert’s service life.

The TNMG22 steel insert can operate at cutting speeds between 300 and 400 meters per minute and feed rates from 0.1 to 0.35 mm per revolution, improving productivity and reducing machining time. Its double-sided design reduces vibration and enhances machining stability. Precise coding includes geometric features, coating type, and dimensional tolerances, enabling quick identification and replacement. Optimal cutting parameters and lubrication can extend tool life up to 90 minutes and ensure high surface finish quality on the workpiece.

Application : کف تراشی و فرم دادن و دیواره زنی
Size : 220408
Machinery : cnc nc
WEBSITE: TNMG22 lathe insert for steel Iran
